Outline of Thermal Print Head

We will stop accepting requests for thermal print head products on January 31, 2021. Please contact your sales representative for details.

"Thermal Print Head (TPH)" is a heat-generating head used for a thermal printer such as direct thermal printer and thermal transfer printer.
Thermal Print Head, which is manufactured by the thick film process, has excellent durabilities (abrasion, pulse and environmental resistance etc.).
We are the first manufacturer worldwide which estab- lished the commercialization of Side Face type as well as Bevel Side Face type successfully, using manufacturing and printing technology of high-precision screen masks which we have cultivated for years. Furthermore we have succeeded to develope and commercialize the new head type called Corner Surface type. Our technology has been and will keep developing consistently.

Main Features

• "Side face type" has heating elements on the side edge of the substrate and "Bevel type" on the bevel edge of the substrate. With this printing technology, printing with- out bending print media is possible./li>
• Mitani's TPH can print extremely-fine lines and at the same time has the world's largest heat quantity by our unique printing and firing technology. Stable printing is possible under severe conditions such as outdoors.

Main Uses

• Various types of cards including rewritable cards and IC cards
• Heavy paper such as cardboard, plastic, metal plate, etc. ・Hang-tag of apparels
• Bus numbered ticket
• Ticketing system of ski resort
• Parking system

Main Models Specifications

Model	configuration	dot density (dpi)	print width (mm)	dot count (dots)	in put voltage (V)	average ohmic value (Ω)	print speed (mm/sec)	Heat history control
MT-S1-4-1ES	Side Face	100	24.0	96	18	320	62.5	-
MT-S1-4-2ES	Side Face	100	32.0	128	24	400	62.5	-
MT-S1-8-1ES	Side Face	200	21.0	168	24	730	62.5	-
MT-S2-4-3ES	Side Face	100	56.0	224	24	380	62.5	-
MT-S2-8-7ES	Side Face	200	40.0	320	24	730	62.5	-
MT-S2-8-1N	Side Face	200	44.0	352	17	425	62.5	-
MT-S2-8-5ES	Side Face	200	48.0	384	24	880	62.5	-
MT-S2-8-5N	Side Face	200	48.0	384	24	880	62.5	-
MT-S3-8-1ES	Side Face	200	56.0	448	24	810	62.5	-
MT-S4-8-5ES	Side Face	200	100.0	800	24	720	62.5	-
MO-S2-8-5A	Side Face	200	48.0	384	24	880	100.0	○
MO-S2-8-7A	Side Face	200	40.0	320	24	800	150.0	-
MO-S2-12-1A	Side Face	300	48.0	576	24	1,400	200.0	○
MO-S2-12-3A	Side Face	300	55.8	672	24	1,400	200.0	-
MO-S2-12-4A	Side Face	300	55.8	672	24	1,100	200.0	○
MT-BS2-8-2ES	Bevel Side Face	200	40.0	320	24	744	62.5	-
MT-BS2-8-6ES	Bevel Side Face	200	48.0	384	24	880	62.5	-
MO-CS2-8-1A	Corner Surface	200	56.0	448	24	600	300.0	-
MO-CS1-12-1A	Corner Surface	300	32.0	384	24	850	400	○
MO-CS2-12-1A	Corner Surface	300	55.8	672	24	850	300.0	-
MO-CS2-12-2A	Corner Surface	300	53.3	640	24	850	400	○
MO-CS2-12-2B	Corner Surface	300	53.3	640	24	1,260	400	○

• * This is a table of our main models and we have a wider range of products. Please feel free to contact us for another models.
• * Custome-made service is available.
• * The above specifications are subject to changes without notice. Please ask our sales staff before ordering.
• * Followings are showing how to understand the system of each model name:
  Model name: ○○-△☆-□-●
  ○○:sort of head (MT: normal, MO: speed printing)
  △ :configuration of head (S: Side Face, BS: Bevel Side Face, CS: Corner Surface, no sign: Flat type)
  ☆ :approx. print width (inch)
  □ :dot density (Ex. 2.7:2.7dots/mm, 4:4dots/mm(100dpi), 8:8dots/mm(200dpi),12:12dots/mm(300dpi)
  ● :other information like order of development, code of IC using etc.

Outline of Thermal Print Head

The new screen print technology of Mitani allows heating element to be placed on the rounded corner of the substrate. This, among others, improves the thermal responsive- ness and enables higher printing speed and accuracy. This new head is called Corner Sur- face type (CS). We developed CS product lines and they are now available on market.

Outline of Thermal Print Head

The new screen print technology of Mitani allows heating ele- ment to be placed on "the rounded corner of the alumina substate". This, among others, improves the thermal responsiveness and enables higher printing speed and qual- ity.

Printing comparison of Corner Type and Side Face Type (Company data)

Features

• ・high-accuracy
• ・high-speed
• ・ink ribbon printing
• ・straight path

Main Specs

• ・300dpi、200dpi
• ・Heating element is possible that distribute on the rounded corner at arbitrary angle.
• ・It is possible that control TDHC

• * Other setting specifications are possible. Please contact us for more details.
• * Patent pending
